Square Rectangular And Round A500 Steel Tube
TIME:2018-06-11
Brief introductionSquare and round A500 steel tube manufacturer and supplier in China.We supply the size from 1/2’’--20’’(20mm—508mm) ,20mmx20mm—500mmx500mmMaterial:Grade A,Grade B,Grade C,Grade D
Here is the introduction of Square And Round A500 Steel Tube:
1.Specification：Round A500 steel tube:1/2’’–20’’(20mm—508mm)
Square and rectangular A500 steel pipe:20mmx20mm—500mmx500mm
2.Length:5.8m, 6m, 11.8m, 12 m and any length can be customized according to customer’s requirement.
3.Surface Treatment：Plain, oiled, painted, galvanized, electro-static coating and so on.
4.Package of square and round A500 steel tube: PVC plastic cloth and in bundles.
5.Transportation:By container or by bulk.
6.Payment: 1.T/T- 30% advance payment, and balance against the copy of B/L within 3-5 days.
2. L/C 100% irrevocable at sight.
3.Western Union
7.Application:Structure
Chemical Requirements
| Element | Grades A, B and D | Grace C | ||
| Heat | Product | Heat | Product | |
| Analysis | Analysis | Analysis | Analysis | |
| Carbon, max | 0.26 | 0.3 | 0.23 | 0.27 |
| Manganese, max | … | … | 1.35 | 1.4 |
| Phosphorus, max | 0.035 | 0.045 | 0.035 | 0.045 |
| Sulfur, max | 0.035 | 0.045 | 0.035 | 0.045 |
| Copper, when copper steel | 0.2 | 0.18 | 0.2 | 0.18 |
| is specified, min | ||||
Tensile Requirements
| Round Structural Tubing | ||||
| Grade A | Grade B | Grade C | Grade D | |
| Tensile strength, mn, ps (MPa) | 45 000 | 58 000 | 62 00 | 58 000 |
| -310 | -400 | -427 | -400 | |
| Yield strength, mn, psi (MPa) | 33 000 | 42 000 | 46 000 | 36 000 |
| -228 | -290 | -317 | -250 | |
| Elongation in 2 in. (50.8 mm), min, %A | 25B | 23C | 21D | 23C |
| Shaped Structural Tubing | ||||
| Grade A | Grade B | Grade C | Grade D | |
| Tensile strength, mn, ps (MPa) | 45 000 | 58 000 | 62 00 | 58 000 |
| -310 | -400 | -427 | -400 | |
| Yield strength, mn, psi (MPa) | 39 000 | 46 000 | 50 000 | 36 000 |
| -269 | -317 | -345 | -250 | |
| Elongation in 2 in. (50.8 mm), min, %A | 25B | 23C | 21D | 23C |
