Cold-rolled stainless steel curtain wall

Cold rolled stainless steel plate is a stainless steel plate produced by cold rolling process, and the general thickness is about 1.5mm~4.0mm. The surface of the cold rolled stainless steel plate can form a special texture pattern, but also improve the strength and flatness of the stainless steel plate, the use of cold rolled stainless steel plate in curtain wall engineering can play a special metal texture of the external wall effect, and greatly improve the flatness of the external wall of the stainless steel plate.

Cold rolled stainless steel plate because of the material’s own characteristics, its surface reflection is high, very sensitive to light and slight deformation will cause obvious visual experience; Its toughness is large, thermal expansion and cold contraction or other slight deformation and displacement will cause a greater impact on curtain wall panel; These characteristics determine that the flatness of the stainless steel curtain wall is higher than that of the ordinary metal curtain wall.
Usually the stainless steel curtain wall is the use of flange processing and V opening process, but the flange processing will produce a slight radian on the edge of the plate and affect the flatness, so for the cold rolled stainless steel plate curtain wall, as far as possible to choose the use of flat stainless steel for design and use; And the thickness of the stainless steel plate has an important impact on the flatness of the realization of different thickness, which also determines the plate to use different processing and assembly technology and structural design. The general use of the cold rolled stainless steel plate in the modern curtain wall is: folded box type, flat type, composite plate type.

Flange box type refers to the plate with the four edges of the V-opening flange processing technology, and combined with the arrangement of reinforcing ribs for plate processing technology. Plate type refers to the use of laser cutting of stainless steel, with a fine cut plate directly used as the curtain wall panel, the plate because there is no folding process, so the plate can achieve extremely high requirements. With higher requirements for curtain wall facade, cold-rolled stainless steel plate as the building curtain wall of the use of high-end materials are more and more, we should choose the right plate according to the specification and the engineering practice and the reasonable system design, cold-rolled stainless steel curtain wall roughness is crucial, plate processing, plate assembly, plate installation shall be implemented without stress production installation.
